| Item | Unit | Parameter | |
|---|---|---|---|
| Power supply | Voltage/Phase/Frequency | 380V/3P/50Hz | |
| Refrigerant | R22 or R404A | ||
| Capacity | kg/24h | 8000 | |
| Cooling Way | Water Cooling | ||
| Temperature | Ambient Temperature | ℃ | 35 |
| Water Temperature | ℃ | 20 | |
| Compressor | Manufacturer | Bitzer/Carrier | |
| Refrigeration Power | kw | 45 | |
| Operating Power | kw | 22.5 | |
| Compressor COP/EER | kw/kw | 2 | |
| Horse Power | hp | 40 | |
| Operating power | Total running power | kw | 25.55 |
| Installation Power | kw | 30 | |
| Power of Reducer | kw | 0.55 | |
| Power of Cold Water Pump | kw | 0.25 | |
| Cooling Water Pump | kw | 1.5 | |
| Fan of Cooling Tower | kw | 0.75 | |
| Dimension | Size of Ice Maker | L×W×H(mm) | 3400×1550×1800 |
| Size of Cooling Tower | L×W×H(mm) | φ1580×2205 | |
| Size of Water Feeding Pipes of Cooling Tower | 3/4" | ||
| Size of Cooling Water Pipes | 2" | ||
| Size of Feeding Pipe | 3/4" | ||
| Size of Ice Outlet | mm | Φ922 | |
| Weight | Weight of Flake Ice Maker | kg | 1800 |
| Operating Weight of Cooling Tower | kg | 460 | |
| Water Supply Pressure Requirement | bar | 1.5 | |
